PFW pump tank
Alpha Line pumping barrel - 14,000 to 20,000 L
The ALPHA Line Tandem drums have an extensive basic equipment. These barrels were designed for professional and intensive use and can be equipped with highly modern technical details. Protect the soil with the Fliegl ALPHA Line Tandem Drum! With an optional tire pressure control system or with the help of a telescopic first axle you reduce the soil pressure and avoid compaction. In addition, there is the option of hydraulic axle shifting to change the drawbar load at the rear of the tractor.
A specially developed drawbar design ensures maximum driving comfort, both in the field and during road travel.
Equipment alpha line - tandem
| S = series | O = optional | X = not available |
| ALPHA Line Tandem (size) | 14000 | 16000 | 18000 | 20000 |
|---|---|---|---|---|
| Container length (jacket) mm | 6500 | 6500 | 6500 | 7000 |
| Container diameter mm | 1700 | 1800 | 1900 | 1900 |
| Bottom hitch with K 80 (1) | S | S | S | S |
| Tiller suspension incl. drum tipping cylinder + drop support foot (PFW 2) | S | S | S | S |
| Compressed air with ALB (1 or 2) | S | S | S | S |
| Axle unit Jumbo Gigant Plus | S | S | S | S |
| Boogie SB axle unit | O | O | O | O |
| Axle unit with air suspension | O | O | O | O |
| Axle unit with hydraulic suspension | O | O | O | O |
| mechanical axle shift | S | S | S | S |
| hydraulic axis shift | O | O | O | O |
| first axis telescopic | O | O | O | O |
| Axle version 410 x 180 | S | S | S | S |
| Caster steering (PFW 2) | S | S | S | S |
| Hydraulic forced steering (2) | O | O | O | O |
| tires 28 L 26 | S | S | S | S |
| Tires 750/60 R 30.5 | O | O | O | O |
| Tires 850/ 50 R 30.5 front 750/60 R 30.5 rear | O | O | O | O |
| Eccentric screw pump Armatec 4000 liters | S | S | S | S |
| Eccentric screw pump Wangen 4000 liters | O | O | O | O |
| Eccentric screw pump Armatec 6000 liters | O | O | O | O |
| Eccentric screw pump Wangen 6000 liters | O | O | O | O |
| Eccentric screw pump cheeks 7500 liters | O | O | O | O |
| Rotary lobe pump Vogelsang 6000 liters | O | O | O | O |
| 6 inch intake valve with quick coupler | S | S | S | S |
| 8 inch intake slide valve with quick coupler | O | O | O | O |
| Push cover 700 x 700 mm hydraulic | O | O | O | O |
| Mounting bracket for trailing shoe distributor and four-point hydraulics | S | S | S | S |
| Level indicator Plexiglas 100 mm (PFW) | S | S | S | S |
| Four-point hydraulics (4500 kg) | O | O | O | O |
| Pump box incl. stone catcher (2) | O | O | O | O |
| Suction nozzle 8 inch (PFW) | O | O | O | O |
| Suction nozzle 8 inch (PFW centered) | O | O | O | O |
| Suction arm top 8 inch length 5000 mm | O | O | O | O |
| automatic pump switching | O | O | O | O |
| Docking with riser pipe at the back top of the drum | O | O | O | O |
| Drum counter (D) | O | O | O | O |
| Top level indicator | O | O | O | O |
| Hydraulic control block (PFW) | O | O | O | O |
| LED working light | O | O | O | O |
| LED light package | O | O | O | O |
| Climbing ladder (PFW) | O | O | O | O |
| Digital flow meter | O | O | O | O |
| Fliegl Slurry Tanker (Isobus slurry tanker control) | O | O | O | O |
| Preparation for NIR sensor | O | O | O | O |
| Tire pressure control system | O | O | O | O |
| Lubrication block | O | O | O | O |
